EVM Storage Layout: Slots, Packing & Cold vs Warm Access

Frequently Asked Questions

01.What is the exact formula for mapping storage slots in Solidity?

For a mapping declared at storage slot `p`, the value associated with key `k` is stored at the slot computed by `keccak256(abi.encode(k, p))`. Both `k` and `p` are left-padded to 32 bytes before concatenation and hashing. For nested mappings, the formula is applied recursively: the inner mapping's slot for key `k1` is `keccak256(abi.encode(k1, p))`, and the value for key `k2` within that inner mapping is stored at `keccak256(abi.encode(k2, keccak256(abi.encode(k1, p))))`. This derivation is specified in the Solidity documentation and has been stable since Solidity 0.5.x (Solidity Storage Layout, docs.soliditylang.org, 2024).

02.When did cold vs warm storage access costs change, and what EIP governs them?

EIP-2929 (State Access Gas Cost Repricing), implemented in the Berlin hardfork on April 15, 2021, introduced the cold/warm access cost distinction. Before Berlin, SLOAD cost a flat 800 gas. After Berlin, first access to any slot in a transaction costs 2,100 gas (cold), and subsequent accesses to the same slot cost 100 gas (warm). EIP-2930 (Optional Access Lists) was activated in the same hardfork, allowing senders to pre-declare storage slots for pre-warming at 2,400 gas per slot. Full specification is at EIP-2929, eips.ethereum.org, 2021.

03.Can storage packing cause bugs in Solidity contracts?

Yes. The most common packing-related bug is assuming that a write to one packed field does not affect adjacent fields in the same slot. The Solidity compiler handles this correctly using bitmask operations, but developers using inline assembly (`sstore`/`sload` directly) bypass these protections and must manually manage bitmasks. A second common issue is that packed storage reads are always 32-byte reads: the full slot is loaded, then the target bytes are extracted. If two threads (simulated via re-entrancy) both read and modify the same slot independently, one will overwrite the other's changes. This is a storage-layer re-entrancy variant and is not prevented by standard OpenZeppelin re-entrancy guards if the guard itself is in a different slot than the data being protected.

04.How does EIP-1153 transient storage differ from regular memory?

Regular Solidity `memory` is allocated per-call and is inaccessible to sub-calls (it does not persist across `CALL` boundaries by default). Transient storage (TLOAD/TSTORE) persists for the entire transaction duration, including across all internal and external sub-calls made during that transaction, but is cleared when the transaction completes. This makes transient storage behave like a transaction-scoped global: a top-level function can write a value via TSTORE, and a deeply nested sub-call can read it via TLOAD, without any ABI encoding overhead. Memory cannot do this across call boundaries without explicit passing as function arguments.

05.What is a storage collision in a proxy contract, and how is it prevented?

A proxy contract stores the address of its implementation contract in a state variable. If that variable is in slot 0 (sequential assignment default), and the implementation contract also declares a state variable in slot 0, every write to the implementation's first variable overwrites the proxy's implementation pointer, bricking the contract or enabling an upgrade hijack. EIP-1967 prevents this by specifying that proxy administrative variables must be stored at `keccak256("eip1967.proxy.implementation") - 1`, which evaluates to a slot far outside the sequential range any implementation contract would reach with normal variable declarations (EIP-1967, eips.ethereum.org, 2019).
